[ASI] - QuickSplit™ 유체분배기

QuickSplit™ 유체분배기
[QuickSplit™ Flow Splitter]

	ASI
	Fixed Flow Splitters, Makeup Splitters Adjustable Flow Splitters

1. 개요

​

• Analytical Scientfic Instruments(ASI)는 다양한 종류의 액체크로마토그래피(HPLC)용 기기와 부속품을 제조하고 있습니다.
• ASI 제품에는 크로마토그래피 사용자가 직면하고 있는 문제점을 해결하기 위하여 고유의 독특한 기술들이 집약되어 있습니다.
• ASI 사의 자흡식 체크밸브(check valves), 유체혼합기(HyperShear™ mixers), 유체분배기(QuickSplit™ splitter) 들은 사용자에게 커다란 만족을 드릴 것입니다.
• 또한 이러한 제품은 HPLC 시스템 제조와 같이 전문적인 기술을 요하는 OEM 분야에서 필요로하는 규격을 만족시킬 수 있습니다.
• ASI QuickSplit™ Flow Splitter(정밀유체분배기)는 단순하면서도 매우 우아한 제품입니다.
• 분배율은 평형상태의 유로를 형성해 주는 2 개 이상의 유체저항기(resistors)에 의해 정해집니다.
• QuickSplit™ Flow Splitter는 고정형과 조정형이 가능합니다.
• 유체저항기만 간단하게 교체하므로써 모세관의 조정과 같은 복잡한 작업없이 신속하게 분배비율을 조정할 수 있습니다.
• LC/MS, 캐피러리 LC, 유체 분류(flow fractionation), 컬럼전/후 유체분배(pre/post-column flow splitting) 등과 같은 높은 재현성을 요구하는 분야에 적합합니다.
• Schematic flow diagram of the QuickSplit™ Fixed Flow Splitter





• Schematic flow diagram of the QuickSplit™ Adjustable Flow Splitter





---

2. 특징

• Fluid resistor technology eliminates tedious adjustments to capillary tubing for split ratio optimization
• Split ratios are stable and reproducible, and not affected by changes in viscosity or pressure
• Adjustable splitters enable precise direct control over split ratios
• Easy to use interchangeable fluid resistors make it possible to achieve split ratios from 1:1 to 20,000:1
• Applications include LC/MS, pre/post-column flow splitting, and flow fractionation
• Multiport flow splitter diverts the inlet flow into 3 or 4 channels for applications that employ multiple detectors and/or a fraction collector
• Rugged stainless steel construction allows high pressure operationLow dead volume fluidic design
• Unique flow path geometry resists clogging better than capillary tube resistors



Post-Column Application	​ ​
Pre-Column Application
Makeup Flow Application

---

3. 주문정보

QuickSplit™ Fixed Flow Splitters for Post-Column Applications

For Post-Column	Flow Rate	Pressure	Split Ratio	Part Number
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	2,000:1	620-PO10-03
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	1,000:1	620-PO10-04
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	500:1	620-PO10-05
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	200:1	620-PO10-06
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	100:1	620-PO10-07
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	50:1	620-PO10-08
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	20:1	620-PO10-09
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	10:1	620-PO10-10
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	5:1	620-PO10-11
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	3:1	620-PO10-12
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	1:1	620-PO10-13
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	<500 psi	Custom	620-PO10-CS
Semi-Preparative Binary Fixed Flow Splitter	5-40 mL/min	<500 psi	20,000:1	620-PO20-00
Semi-Preparative Binary Fixed Flow Splitter	5-40 mL/min	<500 psi	10,000:1	620-PO20-01
Semi-Preparative Binary Fixed Flow Splitter	5-40 mL/min	<500 psi	5,000:1	620-PO20-02
Semi-Preparative Binary Fixed Flow Splitter	5-40 mL/min	<500 psi	2,000:1	620-PO20-03
Semi-Preparative Binary Fixed Flow Splitter	5-40 mL/min	<500 psi	1,000:1	620-PO20-04
Semi-Preparative Binary Fixed Flow Splitter	5-40 mL/min	<500 psi	500:1	620-PO20-05
Semi-Preparative Binary Fixed Flow Splitter	5-40 mL/min	<500 psi	Custom	620-PO20-CS
Preparative Binary Fixed Flow Splitter	30-200 mL/min	<500 psi	Custom	620-PO40-CS
Analytical Three Port Fixed Flow Splitter	0.1-5 mL/min	<500 psi	Custom	630-PO10-CS
Analytical Four Port Fixed Flow Splitter	0.1-5 mL/min	<500 psi	Custom	640-PO10-CS
Semi-Preparative Three Port Fixed Flow Splitter	5-20 mL/min	<500 psi	Custom	640-PO20-CS
Semi-Preparative Three Port Fixed Flow Splitter	5-20 mL/min	<500 psi	Custom	630-PO20-CS
Semi-Preparative Four Port Fixed Flow Splitter	5-20 mL/min	<500 psi	Custom	640-PO20-CS

QuickSplit™ Fixed Flow Splitters for Pre-Column Applications

​For Pre-Column	Flow Rate	Pressure	Split Ratio	Part Number
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	3500 psi	2,000:1	620-PR10-03
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	3500 psi	1,000:1	620-PR10-04
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	3500 psi	500:1	620-PR10-05
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	3500 psi	500:1	620-PR10-06
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	3500 psi	100:1	620-PR10-07
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	3500 psi	50:1	620-PR10-08
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	3500 psi	20:1	620-PR10-09
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	3500 psi	10:1	620-PR10-10
Analytical Binary Fixed Flow Splitter	0.1-5 mL/min	3500 psi	Custom	620-PR10-CS

QuickSplit™ Makeup-Flow Splitter Manifolds

Description	Flow Rate	Pressure	Split Ratio	Part Number
Makeup-Flow Splitter Manifold	1-20 mL/min	<500 psi	1,000:1	620-PO90-01
Makeup-Flow Splitter Manifold	20-50 mL/min	<500 psi	1,000:1	620-PO90-02
Makeup-Flow Splitter Manifold	50-150mL/min	<500 psi	5,000:1	620-PO90-03
Makeup-Flow Splitter Manifold	20-50 mL/min	<500 psi	10,000:1	620-PO90-04
Makeup-Flow Splitter Manifold	Custom	<500 psi	Custom	620-PO90-CS

QuickSplit™ Adjustabble Flow Splitters

For Post-Column	Flow Rate	Pressure	Split Ratio	Part Number
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<500 psi	50-1,000:1	600-PO10-01
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<500 psi	15-250:1	600-PO10-03
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<500 psi	5-100:1	600-PO10-04
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<500 psi	1-20:1	600-PO10-06
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<500 psi	Custom	600-PO10-CS
Semi-Preparative Adjustable Flow Splitter	5-40 mL/min	<500 psi	1,000-20,000:1	600-PO20-00
Semi-Preparative Adjustable Flow Splitter	5-40 mL/min	<500 psi	100-2,000:1	600-PO20-01
Semi-Preparative Adjustable Flow Splitter	5-40 mL/min	<500 psi	15-300:1	600-PO20-02
Semi-Preparative Adjustable Flow Splitter	5-40 mL/min	<500 psi	1-20:1	600-PO20-03
Semi-Preparative Adjustable Flow Splitter	5-40 mL/min	<500 psi	Custom	600-PO20-CS
Semi-Preparative Adjustable Flow Splitter	40-125 mL/min	<500 psi	Custom	600-PO30-CS
Semi-Preparative Adjustable Flow Splitter	75-200 mL/min	<500 psi	Custom	600-PO40-CS
Semi-Preparative Adjustable Flow Splitter	100-1,000 mL/min	<500 psi	Custom	600-PO60-CS

For Pre-Column	Flow Rate	Pressure	Split Ratio	Part Number
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<3500 psi	50-1,000:1	600-PR10-01
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<3500 psi	15-250:1	600-PR10-03
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<3500 psi	5-100:1	600-PR10-04
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<3500 psi	1-20:1	600-PR10-06
Analytical Adjustable Flow Splitter	0.1-5 mL/min	<3500 psi	Custom	600-PR10-CS

​

​
