[LONGER] - T600 속도조절형 OEM 튜브연동펌프

T600 속도조절형 OEM 튜브연동펌프
[T600 Variable Speed OEM Peristaltic Pump]

	LONGER
	스테퍼모터, BCD 스위치 회전속도 : ≤600 rpm 유량범위 : ≤2200 mL/min 펌프헤드 : YZ15, YZ25, DMD15, BZ15, BZ25, DG15,



1. 특징

• Multi-control modes, several pump head are suitable for T100 OEM peristaltic pump.
• Ideal ODM peristaltic pump for lots of instrument.
• Soleplate or panel installation.

---

2.규격

Speed	≤600 rpm
Speed resolution	1 rpm
Direction control	External switch signal. CW when switch is open, CCW when switch is closed
Start/stop control	External switch signal. Pump run when switch is open, stop when switch is closed
BCD dial switch speed control	In low speed range; BCD position 1-F corresponding to 5,10,20,30,40,60,80,100,125,150,175,,200,225,250,275,300 rpm In high speed range; BCD position 1-F corresponding to 320,340,360,380,400,420,460,480,500,520,540,560,580,600 rpm
External speed control	4~20 mA, 0~5 V, 0~10 V, 0~10 kHz
Communacation interface	Available for pump with RS485, Pump ID range is 1-30, 31 is broadcast address, Bit rate; 1200 or 9600 bps
Power supply	DC24V
Power consumption	80W
Operating condition	Temperature; 0~40℃, Relative humidity; <80%
Dimensions	185 L x 120 W x 136 mmH

---

3.주문정보

YZ1515x, YZ2515x		YZII15, YZII25
DMD15-13		DG15-24	​ ​

Installation Drawing

---
