[LONGER] FK-1C 디스펜서 콘트롤러

​ ​​​​​​​	LONGER
	FK-1C 디스펜서 콘트롤러 FK-1C Dispensing Controller Dispensing time : 0-99.99S Pause time :0-99.99S Time resolution : 0.01S Work mode : Single or multiple

---

주문정보

Dispensing Controller
​ ​ ​
Dispensing time			0-99.99S
Pause time			0-99.99S
Time resolution			0.01S
Work mode			Single or multiple
Internal count range			0-999, count up or count down
External count range			999999，0 means unlimited cycle
External Start/Stop			Open circuit
Memory function			Repower the pump, user can choose whether to continue in accordance with the state before the power-down
Power supply			AC 220V/5W
Type		Product code		Function
FK-1C		05.49.25A		Dispensing controller can be equipped with many peristaltic pumps, gear pumps to realize dispensing automatically.

Foot Switch
​ ​ ​
Type	Product code	Connector	Applicable	Function
JK-1	05.49.20A	DB-9	Peristaltic Pumps	Gated: Pump stops when it is powered on. Pump runs when press down the footswitch; and pump stops when release the footswitch. Trigger: Pump stops when it is powered on. Pump runs when footswitch is pressed once, and pump will stop when footswitch is pressed again.
JK-2	05.49.20B	DB-9	Dispensing Controller	Trigger: Pump stops when it is powered on. Pump runs when footswitch is pressed once, and pump will stop when footswitch is pressed again.
JK-3	05.49.20C	DB-15	Peristaltic Pumps	Gated: Pump stops when it is powered on. Pump runs when press down the footswitch; and pump stops when release the footswitch.
JK-4	05.49.20D	DB-9	LSP Syringe Pumps	Gated: Pump stops when it is powered on. Pump runs when press down the footswitch; and pump stops when release the footswitch. Trigger: Pump stops when it is powered on. Pump runs when footswitch is pressed once, and pump will stop when footswitch is pressed again.
JK-5	05.49.20E	DB-15	TJ Syringe Pumps	Trigger: Pump stops when it is powered on. Pump runs when footswitch is pressed once (press down and release), and pump will stop when footswitch is pressed again.
JK-6	05.49.20F	None	TS Syringe Pumps	Trigger: Pump stops when it is powered on. Pump runs when footswitch is pressed once (press down and release), and pump will stop when footswitch is pressed again.
JK-8	05.49.20H	9-pin	YT600-1J	​
JK-9	05.49.20I	9-pin	WT600-3J	​
JK-10	05.49.20J	9-pin	WT600-4F	​
JK-11	05.49.20K	DB-15	Peristaltic Pumps	​
JK-12	05.49.20L	DB-9	Peristaltic Pumps	​
JK-13	05.49.20M	None	FK-100Z	​
JK-14	05.49.20N	BNC	LLP01-100	​

External Control Interface
​ ​ ​
Type	Product code	Connector	​
0~5 V	05.49.31A	DB-15	BQ50-1J, WT3000-1JA, BT100-2J, BT100-1F, WT3000-1FA, BT300-2J, BT300-1F, WT3000-1JB, BT600-2J, WT600-2J, WT3000-1FB, WT600-1F
0~10 V	05.49.31B	DB-15
4~20 mA	05.49.31C	DB-15
0~10 kHz	05.49.31D	DB-15
RS-485	05.49.31E	DB-15
WK-01	-	-	Change (4-20mA, 0-5V, 0-10V) on the basis of standard analog external control module on the increase in internal and external control conversion.
Wk-02	-	-	Switching control start and stop supporting OEM100J-75
WK-03	-	-	Switching control start and stop supporting OEM100J-75
WK-04	-	-	Switching control peristaltic pump (except aeronautical product plug interfaces) start and stop, stop short, disconnected operation
WK-05	-	-	Switching control peristaltic pump WT600-3J, WT600-4F start and stop
WK-06	-	-	Switching control start and stop, fault alarm output by the extraction module
WK-07	-	-	WK-04 module controls the start and stop logic is inverted; short run, stop off
WK-08	-	-	External control only controls the start and stop buttons control the speed of the internal control, 5V stopped, suspended the operation according to the original state
WK-09	-	-	External control only controls the start and stop buttons control the speed of the internal control, 24V stopped, suspended the operation according to the original state
WK-10	-	-	External control switch start and stop and direction control, speed control button internal, supporting BT100-2J-12 & YZ1515X
WK-11	-	-	Increase external control switch function on the basis of external control 0-10V
WK-12	-	-	And supporting the use of BT100-2J-18, DB15 connected to drive external control interface, DB9 pin 2 Take 0-10V negative, positive needle 5 then 0-10V
WK-17	-	-	Adaptation LSP02-1B-1, by switching control and direction of the pump start and stop.
WK-18	-	-	Supporting BT100-2J-21
WK-19	-	-	Supporting the use TJ-3A-5, switch control, external control start and stop and direction control
​
